G-140W-MD 1GE+3FE +Wifi Gpon ONU

G-140W-MD Wifi Gpon ONU Datasheet

Product Description:

The G-140W-MD, an optical network terminal d for home and SOHO users. The G-140W-MD provides one POTS port, three FE auto-adapting Ethernet ports,one GE port(ONT), is a high-end home gateway in FTTH solution. By using the GPON technology, ultra-broadband access is provideE auto-adapting Ethernet port and one Wi-Fi port. The G-140W-MD features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services. Therefore, the G-140W-MD provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment.

Specificaton:

Product Highlights:

1. 1.Plug-and-play (PnP): Internet, IPTV and VoIP services can be deployed by one click on the NMS and on-site configuration is not required.

   2.Remote diagnosis: Remote fault locating is implemented by the loop-line test of POTS ports, call emulation and PPPoE dialup emulation initiated by the NMS.

   3.Link monitoring: E2E link detection is achieved using 802.1ag Ethernet OAM.

   4.High speed forwarding: GE line rate forwarding in the bridging scenario and 900 Mbit/s forwarding in the NAT scenario.

   5.Green energy-saving: 25% power consumption is saved with highly integrated system on chipset (SOC) solution, in which, a single chip integrates with PON, voice, gateway and LSW modules.

GPON features:

*Class C+ optical module

*Security authentication mode: SN,
password or SN+password

*Upstream/downstream FEC

Routing features:

*NAT function

*Internet, IPTV and VoIP services are automatically bound to ONT ports

*Virtual server, port trigger, DMZ,and DDNS

Reliability features:

*Dual systems for software protection

*Type B protection and rogue ONT detection

*Lithium battery backup and backup battery monitoring

Maintenance features:

*Local management using Web and remote management using TR069 and OMCI

*Optical power monitoring

*802.1ag Ethernet OAM

*Loop-line test of POTS ports,call emulation and PPPoE dialup emulation

Green engery-saving features:

*Dynamic power consumption adjustment

*With a backup battery, the guaranteed services can be selected flexibly

Voice features:

*SIP and H.248 protocols

*Media stream and signaling stream separation

Multicast features:

*IGMP V2&V3 snooping/IGMP proxy

Wi-Fi features:

*802.11b/g/n, certified by the Wi-Fi Alliance
