F670L 4GE +Pot + Dual Band Wifi Gpon ONU

PRODUCT ID3678288CATEGORYONUAVAILABILITYInquiry open

The F670L is a high-performance GPON optical network unit (ONU) designed for next-generation FTTH (Fiber to the Home) broadband networks. It serves as an all-in-one solution, combining robust wired connectivity with high-speed wireless coverage.

Product overview and specifications

F670L 4GE Dual Band Wifi Gpon ONU

Description:

F670L FTTH is a dual band Gigabit Premium triple-play GPON gateway. It comes with 1GE&3FE LAN ports, one phone port and next generation multi-stream Wi-Fi, operating simultaneously in 2.4GHz 2×2 over 802.11n and 5GHz 2×2 over 802.11ac. Based on customer requirements, the maximum 5dBi gain antennas can enhance the Wi-Fi coverage area and improve the performance.

Specifications:

Model	F670L
GPON Port	1x, SC/APC, 2,448 Gbit/s downstream 1,244 Gbit/s upstream
Subscriber interface	4GE+1pots+1USB+WIFI 2.4G &5G
Modes	Bridge, Router, AP
Wavelength downstream	1490nm
Upstream Wavelength	1310nm
Sensitivity	-28 dBm
Consumption	9 W
Dimensions	205 x 120 x 28 mm
Working temperature and humidity	0°C – 40°C, 5% – 95%
Power	12 IN DC
GPON properties	8x T-CONT, 32 GEM ports
Support	VLAN (802.1Q, 802.1P, 802.1ad), Multicast, QoS, DHCP Server/Client, NAT, IPv6 Dual Stack
Management	Local (WEB), OMCI, TR069

Features:

Flexible Management Mode

The F670L can be managed by two ways: one is complete OMCI complying with ITU-T G.988, the other is OMCI plus TR-069 complying with BBF TR-142 framework. Service providers can choose their preferred ways to manage the device.

Quality of Service (QoS)

The QoS features of the F670L enable service providers to design QoS policies and prioritize mission-critical services such as IPTV and VoIP freely based on their individual service plans. So, service providers could deliver real multi-play applications to users and increase network efficiency.

Highly Reliable Feature

Dual-Band concurrent Wi-Fi mode so that its Wi-Fi speed can reach up to 1.2Gbps, consisting of 300Mbps (802.11n 2×2 @ 2.4GHz) and 866Mbps (802.11ac 2×2 @5GHz). The dual image ensures uninterrupted services during software download or upgrade, thereby enhancing software reliability. The highly reliable lightning protection design provides lightning and surge protection of 4 kV for the adapter, 1.5 kV for the POTS port, and 1.5 kV for the Ethernet ports.
