DETAILED INTRODUCTION
Product overview and specifications
F663NV3A 1GE+1FE Wifi Gpon ONU
F663NV3a FTTH Product Overview
F663NV3a FTTH is a single-frequency and economical smart gateway. This model uses the new-generation self-developed chip, loads the intelligent operating system, and supports dynamic loading of plug-ins, and givess users with abundant home services. The stable wireless performance provides smooth Wi-Fi for the home. Its unique open application platform creates an operator-dominated and user-centered smart home application ecosystem.
F663NV3a FTTH Product Specifications
| Technical items | Descriptions |
| Model | F663NV3a |
| Fiber interface | SC/UPC |
| Fiber port | 1 GPON interface, 1GE+3FE+1POT+1USB+WIFI,SC single-mode, |
| Downstream rate 2.5Gbps, Upstream rate 1.25Gbps | |
| Wavelength | Tx 1310nm, Rx 1490nm |
| Voice protocol | SIP, H.248 |
| RX sensitivity | <-27dBm (1490nm) |
| WLAN | IEEE802.11b/g/n,2*2 MIMO, 2.4G WIFI,external antenna |
| Net weight | ≤0.6Kg |
| Configuration method | NMS, Web, or TR069 |
| Power | ≤8W |
| DC power | Adapter input: 100-240 V AC, 50 – 60 Hz ; |
| Adapter output: 11 – 14 V DC, 1 A | |
| Button | Reset, power |
| Operation | Working temperature: -0-+40℃ |
| working humidity:5-95%(non-condensation) | |
| Dimension | 250*220*65mm(length*width*height) |
| L2 forwarding capability | Forwarding packets of any length at wire speed |
| IPv4 L3 forwarding capability | 2Gbit/s with any length packets in downstream direction |
| 1Gbit/s with any length packets in upstream direction | |
| IPv6 L3 forwarding capability | 2Gbit/s with any length packets in downstream direction |
| 1Gbit/s with any length packets in upstream direction | |
| LAN | 1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface |
F663NV3a FTTH Product Features
- highly reliable heat dissipation design guarantees its stable operation.
- dual image ensures uninterrupted services during software downloading or upgrading, thereby enhancing software reliability
- highly reliable lightning protection design provides lightning and surge protection of 4 kV for the adapter, 1.5 kV for the Phone interfaces, and 1.5 kV for the Ethernet ports.
- full-service access capability featuring high bandwidth, high performance, high reliability, and easy operation, administration and maintenance (OMCI/TR-069) meets the continuously changing requirements of the customer, protects the legacy investment, and enhances the value of the operator’s network.
