DETAILED INTRODUCTION
Product overview and specifications
HG8321V 1GE+1FE +POT +CATV Gpon ONU
HG8321V FTTH is a bridging-type ONT used in the all-optical access solution. The product implements ultra-broadband access through the GPON technology. At the same time, HG8321V provides 1 GE port 1FE Portand 1 RF port. The high-performance forwarding capability ensures the service experience of CATV,data and HD video services, and offers users with ideal terminal solutions and future-oriented service support capabilities.
HG8321V FTTH Product Specifications
Model | HG8321V |
Port | 1GE+1FE+1POTS+ 1 CATV/RF Port |
Interface Type | SC/APC, CLASS B+ |
PON Interface | Uplink: 1.25Gbps; Downlink: 2.5Gbps |
Size (Mm) | 167(L)×118(W)×30(H) |
Weight | <0.5KG |
Maximum Power Consumption | <8W |
Weight | 120g |
Power Supply | External Power Adapter 12V/1A |
Power Adapter Input | 100-240V AC, 50/60Hz |
Power Interface Size | metal inner diameter: φ2.1±0.1mmouter diameter : φ5.5±0.1mm; length: 9.0±0.1mm |
WLAN Module | External dual antenna, antenna gain 5db, antenna power 16~21dbm |
Support 2.4GHz, 300M transmission rate | |
Operating Environment | Temperature: -10°C ~ 55°C |
Humidity: 5% ~ 95% (no condensation) |
HG8321V FTTH Product Features
- Full compatible with ITU-T G.984
- Support software online upgrading
- Support Dynamic Bandwidth Allocation (DBA)
- Support broadcasting storm resistance function
- Support port isolation between different ports
- Support port-based rate limitation and bandwidth control
- Support ACL and SNMP to configure data packet filter flexibly
- Integrated OMCI remote configuration and maintenance function.
- Support ONT auto-discovery/Link detection/remote upgrade of software;
- Support VLAN division and user separation to avoid broadcast storm;
- Specialized design for system breakdown prevention to maintain stable system
- EMS network management based on SNMP ,convenient for maintenance
