EG8147X6-10 Wifi6 AX3000 +CATV Xpon ONU Datasheet
Product Description:
EG8147X6 FTTH is an intelligent Wi-Fi 6 routing-type Optical Network Terminal with four GE ports, one POTS port, one CATV port, and one USB port, plus 2.4G and 5G Wi-Fi connectivity. It adopts Gigabit Passive Optical Network (GPON) technology to offer ultra-broadband access, high performance, and wide coverage for users. With high forwarding performance, EG8147X6 FTTH gives the customers high-quality experience for voice, data, and High Definition (HD) video services — along with future-oriented service support capabilities —EG8147X6 helps enterprises construct powerful all-optical access Solutions.
Specifications:
Model | EG8147X6 |
Dimensions (H x W x D) | 35 x 220 x 145 mm |
Weight (Without Power Adapter) | < 600 g |
Operating Temperature | 0–40°C |
Operating Humidity | 5–95% RH (non-condensing) |
System Power Supply | 11–14 V DC, 1.5 A |
Power Adapter Input | 100–240 V AC, 50/60 Hz |
Maximum Power Consumption* | 18W |
NNI | GPON |
UNI | 4 x GE, 1 x POTS, 1 x CATV, 2.4G/5G Wi-Fi 6, 1 x USB |
Installation Mode | Desktop |
Authentication | 802.1X |
Product Features:
- Port type: SC/APC
- Class B+
- Receiver sensitivity: –27 dBm to –29 dBm
- Overload optical power: –8 dBm
- Wavelengths: US 1310 nm, DS 1490 nm
- Wavelength Blocking Filter (WBF) of G.984.5
- Flexible mapping between the GEM port and TCONT
- GPON: consistent with the SN or password authentication defined in G.984.3
- Bi-directional FEC
- SR-DBA and NSR-DBA
- Ethernet port-based VLAN tags and tag removal
- Limit on the number of learned MAC addresses
- MAC address learning
- Auto port speeds (10/100/1000 Mbit/s)
- IEEE 802.11 b/g/n/ax (2.4G)
- IEEE 802.11 a/n/ac/ax (5G)
- 2 x 2 MIMO (2.4G) 2 x 2 MIMO (5G)
- Antenna gain: 5 dBi
- WMM/Multiple SSIDs/WPS
- 2.4G and 5G concurrency
- Air interface rate: 574 Mbit/s (2.4G), 2.402 Gbit/s (5G)
- Maximum REN: 4
- G.711A/μ, G.729a/b, and G.722 encoding/decoding
- Emergency calls (with the SIP protocol)
- Frequency Range 54–1000 MHz
- Output resistance 75 ohms
